Technical Parameter
| ACCURACY for CS-68 CS-6.8 | TOLERANCE(Max.) |
| Parallelisom of table surface to baset | .0006.015m/m |
| Axial movement of table suiface | .0006.015m/m |
| True running of center boss | 0004″.01m/m |
| Squarenese of base to angle face per12″ | 0008″.02m/m |
| Positionong sccuracy | 45 sec. |
| MODEL NO. |
Chuck | Face Plate | ||||
| Outer Dia. |
ThruHole Dia. |
Inner Jaw | OuterJaw | Outer Dia. | Thickness | |
| CS-6 | 167 6.30 |
50 1.57 |
4-60 0.12~2.17 |
55-150 2.17-5.71 |
205 8.07 |
42 1.57 |
| CS-8 | 210 7.87 |
63 2.56 |
4-85 0.16~3.35 |
65-200 2.55-7.87 |
254 10 |
42 1.65 |
| MODEL NO. |
Guide Block |
Turret Hole Dla |
A | B | C | a | b | C | d | e | f | 9 | h | i | j | k | Gross Weight kgs/ibs |
| CS-6 | 16 0.63 |
50 1.97 |
250 9.84 |
238 9.37 |
220 8.15 |
182 7.17 |
140 5.51 |
186 7.32 |
96 3.66 |
112 4.41 |
105 2.56 |
16 0.63 |
122 4.80 |
191 7.52 |
80 3.15 |
16 0.63 |
3 70 |
| CS-8 | 16 0.63 |
63 2.48 |
325 12.60 |
300 11.57 |
267 9.27 |
236 9.06 |
160 6.30 |
220 9.27 |
96 3.66 |
126.5 4.99 |
137 2.95 |
16 0.63 |
155 6.10 |
234.67 9.24 |
95 3.74 |
18 0.79 |
52 114 |
