Technical Parameter
| MODEL NO. | 3 STEPS CLAMPING POSITION | ||
| X | Y | Z | |
| HP-4V | 0-60 | 57-115 | 110-170 |
| HP-5V | 0-72 | 70-140 | 135-220 |
| HP-6V | 0-100 | 98-200 | 195-305 |
| HP-8v | 0-100 | 98-200 | 195-305 |
| MODEL NO |
JAW WIDTH (A) |
JAW DEPTH (a) |
JAW OPENING (C) |
D | E | F | G | H | 1 | J | K | L | CLAMPING FROCE |
WEIGHT | |
| Plain | W/Swivel Base |
||||||||||||||
| HP-4v | 100 4 |
36 1.42 |
170 6.7″ |
525 | 430 | 130 | 160 | 94 | 60 | 78 | 100 | 155 | 2600kgs 5720ibs |
16kgs 36ibs |
22kgs 48.5ibs |
| HP-5v | 125 5 |
46 1.81″ |
220 8.66 |
670 | 540 | 165 | 185 | 118 | 72 | 97 | 117 | 185 | 3500kgs 7700ibs |
32kgs 70.4ibs |
42kgs 92.4ibs |
| HP-6v | 155 6 |
53.6 2.10 |
305 12 |
960 | 615 | 202 | 232 | 136 | 82 | 115 | 125 | 255 | 4600kgs 10120ibs |
58kgs 128ibs |
75kgs 165ibs |
| HP-8v | 200 8″. |
62 2.44 |
305 12 |
1020 | 700 | 240 | 280 | 162 | 100 | 160 | 165 | 266 | 7200kgs 15840ibs |
96kgs 212ibs |
125kgs 275ibs |
